Wide Power Range: Configurable from 60kW to 480kW to meet diverse site and vehicle requirements
Versatile Application Scenarios: Ideal for bus stations, taxi hubs, logistics parks, and highway service areas
Multi-Vehicle Compatibility: Supports electric buses, logistics vehicles, passenger cars, and special-purpose EVs
Flexible Charging Modes: Offers automatic full charge, time-based, energy-based, and cost-based charging options
Smart Power Distribution: Enables efficient resource utilization with dynamic power allocation
Robust Safety Protection: Includes short circuit, overcurrent, overvoltage, leakage, and lightning protection
User-Friendly Interface: Features a 7-inch display with real-time charging status and three status indicators: power, charging, fault
Secure Authentication System: Supports IC card-based transactions with a comprehensive card management system
| MODEL | WREVC-25-480 | ||
| Maximum output power | 60kW-480kW | Protection Features | Lightning protection, overvoltage protection, overcurrent protection, emergency stop protection, short circuit protection, etc. |
| Input Voltage Range | 380Vac±15% | ||
| Operating frequency | 45Hz～65Hz | Environmental Conditions | |
| Input current harmonic | ≤5% | Operating temperature: -25°C to 55°C | |
| Power factor | ≥0.99 | Relative humidity: 5% to 95% | |
| Output Voltage Range | DC 200V～1000V | Charging Modes | Fixed amount mode, timed mode, fixed quantity mode, automatic full-charge mode, scheduled charging |
| Charging interface | Single gun/ | ||
| Voltage regulation accuracy | ≤±0.5% | Protection Functions | IP54 |
| Current regulation accuracy | ≤±1% | User Interface | 7-inch touch screen |
| Maximum efficiency | ≥96% | Charging interface | Single gun、 Double gun optional |
| Communication interface | Ethernet (4G Optional) | Cooling method | Air cooling |
